SmartAXIS Touch User’s Manual 11-5
1 Bit Write Command
11
Commands
■ Destination Device
Specify the destination bit device.
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
■ Write
Specify the number of bit devices (1 to 64) at the destination.
This setting is enabled only if Action Mode is set to Set or Reset.
Example: This fills a contiguous block of bit devices with the same value.
If the bit of the word device is specified, the same value is written to same bit of contiguous word devices.
■ Source Data
Specifies the device where the data to be written is stored.
This setting is enabled only if Action Mode is set to Move.
Example: This button writes the values in a contiguous block of bit devices to a contiguous block of devices at the
destination.
*1 Advanced mode only
Toggle: Toggles the value of the specified bit device when the trigger condition is satisfied.
If the value of the bit device is 0 it changes to 1, and vice versa.
Move: This function writes the value in the source bit device to the value in the destination bit device
when the trigger condition is satisfied.
State of condition
Action
Toggle
Toggle
Condition Condition Condition Condition
Satisfied
Satisfied
Satisfied
Not satisfied
Not satisfied
Not satisfied
Satisfied
Satisfied
SatisfiedNot satisfied
Not satisfied
Not satisfied
State of condition
Action
Move
Move
Condition Condition Condition Condition
SatisfiedSatisfiedSatisfied
Not satisfiedNot satisfiedNot satisfied SatisfiedSatisfiedSatisfiedNot satisfiedNot satisfiedNot satisfied
*1
1M0
1M1
1M2
1M3
1M4
Action Mode: Set
Write: 5
Destination Device: M0
Condition
SatisfiedSatisfiedSatisfied
Condition
bit bit
15 0
SatisfiedSatisfiedSatisfied
1D0
D1
D2
D3
D4
1
1
1
1
Action Mode: Set
Write: 5
Destination Device: D0-15
Device: Specify the source bit device.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Transfer: Specify the number of bit devices (1 to 64) to move.
1LM0
0LM1
0LM2
1LM3
Device: LM0
Transfer: 4
Destination Device: M0
1M0
0M1
0M2
1M3
Condition
SatisfiedSatisfiedSatisfied
