SmartAXIS Touch User’s Manual 13-15
3 Alarm Log Settings Dialog Box
13
Alarm Log Function
■ Call Popup Screen
These settings configure the Popup Screen to display when an alarm occurs. The Popup Screen displayed when an
alarm occurs is called the alarm screen.
■ Number of Stored Data
Specifies the maximum amount of Alarm Log data saved in the data storage area. Data is saved up to the set amount.
The maximum amount of data that can be saved in the data storage area is 5011.
Click to open the Data Storage Area Management dialog box. You can change the allocation of data storage area
memory in the Data Storage Area Management dialog box. For details, refer to Chapter 16 “Data Storage Area” on
page 16-1.
Call Popup Screen: Select this check box to display the alarm screen when an alarm occurs.
Screen No.: Specifies the alarm screen number (1 to 3015) to display when an alarm occurs.
Coordinates X, Y: Specifies the coordinates to display the alarm screen.
With the upper-left corner of the screen as the origin, the upper-left corner of the
alarm screen is the X and Y coordinates.
Specify the coordinates in 1 dot units.
X: 0 to (Base Screen horizontal size - 1)
Y: 0 to (Base Screen vertical size - 1)
