6. Web Menu System
6-60
9)
Type of Service
Type of service embedded in packet header. Range: 1 to 255
When it remains blank, the filter is adopted to all Type of Service.
10)
Type of Mask
Mask to define adapted type-of-service. Range: 1 to 255
This item is required when “9) Type of Mask” was input.
Downlink Traffic Flow Filter
Contents
11)
Source Address
Source address adapting Downlink Traffic Flow Filter
When it remains blank, the filter is adopted to all IP address.
12)
Subnet Mask
Subnet mask for adapting Downlink Traffic Flow Filter
13)
Protocol No.
Protocol number for adapting Downlink Traffic Flow Filter
Range : 1 to 255
When it remains blank, the filter is adopted to all protocols.
14)
Destination Port Range
Destination Port Range for adapting Downlink Traffic Flow Filter
Range: 1 to 65535. “-” represents range. Ex) 20-80 set from 20 to 80.
When it remains blank, the filter is adopted to all TCP/UDP port.
15)
Source Port Range
Source Port Range for adapting Uplink Downlink Flow Filter
Range: 1 to 65535. “-” represents range. Ex) 20-80 set from 20 to 80.
When it remains blank, the filter is adopted to all TCP/UDP port.
16)
Type of Service
Type of service embedded in packet header. Range: 1 to 255
When it remains blank, the filter is adopted to all Type of Service.
17)
Type of Mask
Mask to define adapted type-of-service. Range: 1 to 255
This item is required when “16) Type of Mask” was input.
