PROGRAM mode: HD-1
102
Pan (CC#8) (Post IFX Pan) [L000…C064…R127]
Specifies the panning immediately after the insert effect.
You can use CC#8 to control this.
Bus Sel. (Bus Select) [L/R, 1…4, 1/2…3/4, Off]
Specifies the bus to which the signal will be sent
immediately after the insert effect.
L/R: The signal will be sent to the L/R bus, which passes
through TFX 1 and 2 and then goes to the main L/R outputs.
This is the default setting.
1…4: The signal will be sent, in mono, to the selected
individual output.
1/2, 3/4: The signal will be panned by the Pan (CC#8)
setting, and sent in stereo to the selected pair of audio
outputs.
Off: The signal will not be sent directly to the outputs. This
setting is useful if you want to:
•Use Send 1 or 2 to route the signal entirely through the
master effects, without sending the dry signal to the
outputs.
•Use the FX Control Bus to route the signal to an effects
side-chain, such as a gate or vocoder, without being
heard directly at the outputs.
•Use the REC Bus to record the signal, without routing
the signal directly to the outputs.
FX Control Bus [Off, 1, 2]
This sends the post-IFX signal to the FX Control busses. For
more information, see “8–1d: FX Control Bus” on page 99.
REC Bus [Off, 1, 2, 3, 4, 1/2, 3/4]
Sends the post-IFX signal to the REC busses. For more
information, see See “8–1e: REC Bus” on page 99. If you
want to resample via the REC busses, set the sampling
Source Bus (0–8d) to REC 1/2 or REC 3/4.
Send1 [000…127]
Send2 [000…127]
These adjust the level at which the post-IFX signal is sent to
master effects 1 and 2. This is valid if Bus Select (8–5a) is
set to L/R or Off.
You can use CC#93 to control the Send 1 level, and
CC#91 to control the Send 2 level. The global MIDI
channel specified by MIDI Channel (GLOBAL 1–1a) is
used for these messages.
IFX2…12
Here you can specify each insert effect’s effect type, on/off
status, chaining, and mixer settings following the insert
effect. With the exception of Chain to and Chain, the
parameters are the same as for IFX1. See “IFX1” on
page 101.
IFX2: Chain to [IFX3…IFX12]
IFX3: Chain to [IFX4…IFX12]
IFX4: Chain to [IFX5…IFX12]
IFX5: Chain to [IFX6…IFX12]
IFX6: Chain to [IFX7…IFX12]
IFX7: Chain to [IFX8…IFX12]
IFX8: Chain to [IFX9…IFX12]
IFX9: Chain to [IFX10…IFX12]
IFX10: Chain to [IFX11…IFX12]
IFX11: Chain to [(IFX12)]
These specify the chain destination for each insert effect. If
Chain is enabled, the insert effect will be connected in series
to the IFX specified by the Chain to setting.
The only chain destination for IFX11 is IFX12. You cannot
chain IFX12 to another IFX.
Chain [Off, On]
Specifies whether insert effects will be connected in series.
If the Chain check box is on, this insert effect will be
connected in series to the insert effect selected by “Chain
to.” This is not available for IFX12.
Tip: If you move from this page to the IFX– IFX1–12 page,
the IFX you choose here will be selected.
v
8–5: Page Menu Commands
• Compare →p.112
• Write Program →p.112
• Exclusive Solo →p.113
• Copy Insert Effect →p.122
• Swap Insert Effect →p.122
• Insert IFX Slot →p.122
• Cut IFX Slot →p.123
• Clean Up IFX Routings →p.124
• PAGE →p.126
•MODE →p.126
