SAMPLING mode
596
8–1c: FX Control Bus
FX Control Bus [Off, 1, 2]
This sends the output of the oscillator (multisample) to a FX
Control bus (stereo 2-channel; FX Ctrl1, 2)
Use the FX Control buses when you want to use a separate
sound to control the input of an effect. You can use the two
(stereo 2-channel) buses to control effects freely.
For more information, please see “FX Control Bus” on
page 583.
8–1d: REC Bus
REC Bus (All OSCs to) [Off, 1…4, 1/2, 3/4]
This sends the output of the oscillator (multisample) to the
REC buses (four mono channels; 1…4). If you want to
resample from the REC buses, set Source Bus to REC1/2 or
REC3/4.
The REC buses are used to sample in each mode, and to
record audio tracks in SEQUENCER mode. They are
dedicated buses for recording.
Off: The oscillator output will not be sent to the REC buses.
Normally you will leave this Off.
1…4: The oscillator output will be sent in monaural to the
corresponding REC bus.
1/2, 3/4: The oscillator output will be sent in stereo to the
corresponding pair of REC buses.
8–1e: OSC MFX Send
Send1 (to MFX1) [000…127]
Send2 (to MFX1) [000…127]
This sets the send levels at which the output of the oscillator
(multisample) is sent to the master effects. The master
effects are sent to the L/R bus. Set the Source Bus to L/R if
you want to use master effects while resampling.
You can use CC#93 to control the Send 1 level and
CC#91 to control the Send 2 level. The global MIDI
channel specified by MIDI Channel (GLOBAL 1–1a) is
used for these messages.
8–1f: Tempo
(Tempo) [040.00…300.00, EXT]
This is the Global tempo, as used for controlling effects, etc.
v
8–1: Page Menu Commands
• Copy Insert Effect →p.122
• Swap Insert Effect →p.122
•PAGE →p.126
•MODE →p.126
