Parameters:
<Boolean> OFF - independent color scheme in new diagram area. Moved
traces change their color.
ON - color scheme in new diagram area continues the previous
color scheme. Moved traces keep their color.
Example:
*RST; :DISP:CMAP13:RGB 1,0,0
Create diagram area no. 1 (with default trace showing the S-
parameter S
21
) and color the trace red.
DISP:CMAP:TRAC:COL OFF; :DISP:WIND2:STAT ON
Select independent color schemes for new diagram areas. Cre-
ate a new diagram area no. 2.
CALC:PAR:SDEF 'Trc2', 'S11'; :DISP:WIND2:TRAC2:
FEED 'TRC2'
Create a new trace named Trc2 and display the trace in a new
diagram area no. 2. The new trace is red like the first trace.
DISP:CMAP:TRAC:COL ON; :DISP:WIND3:STAT ON
Continue the same color scheme in new diagram areas. Create
a new diagram area no. 3.
CALC:PAR:SDEF 'Trc3', 'S22'; :DISP:WIND3:TRAC3:
FEED 'Trc3'
Create a new trace named Trc3 and display the trace in a new
diagram area no. 3. The new trace is not red.
Manual operation:
See "General > Trace Colors per Diagram" on page 692
DISPlay:CMAP:TRACe:RGB <TraceName>, <Red>, <Green>, <Blue>[,
<TraceStyle>, <TraceWidth>]
Defines the color, style and width of a trace referenced by its name, based on the Red/
Green/Blue color model. Use the generalized command DISPlay:CMAP<DispEl>:
RGB to define the color of other display elements.
Parameters:
<TraceName> Trace name, string parameter
<Red> Red content of the defined color.
Range: 0 (zero intensity, corresponding to a 0 in the 24-bit
color model) to 1 (full intensity, corresponding to
255 in the 24-bit color model).
<Green> Green content of the defined color.
Range: 0 (zero intensity, corresponding to a 0 in the 24-bit
color model) to 1 (full intensity, corresponding to
255 in the 24-bit color model).
<Blue> Blue content of the defined color.
Range: 0 (zero intensity, corresponding to a 0 in the 24-bit
color model) to 1 (full intensity, corresponding to
255 in the 24-bit color model).
