<TraceStyle> SOLid | DASHed | DOTTed | DDOTted | DDDotted
Optional trace style, only for traces (<DispEl> > 12): One of the
string parameters SOLid | DASHed | DOTTed | DDOTted
| DDDotted.
<TraceWidth> Optional trace width, only for traces (<DispEl> > 12).
Range: 1 to 20
Example:
*RST; :DISP:CMAP:TRAC:RGB 'Trc1', 1, 0, 0
Color the default trace 'Trc1' red.
See also DISPlay:CMAP<DispEl>:RGB
Manual operation: See "Properties" on page 691
DISPlay:LAYout <LayoutMode>
Arranges the diagrams in the screen, leaving the diagram contents unchanged.
Parameters:
<LayoutMode> LINeup | STACk | HORizontal | VERTical | GRID
LINeup – the diagrams are arranged side by side.
STACk – the diagrams are arranged one on top of the other.
HORizontal – the diagrams are arranged in horizontal rows.
VERTical – the diagrams are arranged in vertical rows.
GRID – the diagrams are arranged as a rectangular matrix. The
number of rows and columns is as defined with command
DISPlay:LAYout:GRID.
Example: See DISPlay:LAYout:GRID
Manual operation: See "Split Type" on page 687
DISPlay:LAYout:APPLy <LayoutId>
Selects a previously defined layout for display in the analyzer screen.
Parameters:
<LayoutId> Integer value 1, 2 ...
Current number, as defined by DISPlay:LAYout:DEFine.
Example: See Creating Diagrams
Manual operation: See "Additional Functionality: SCPI Commands" on page 687
DISPlay:LAYout:DEFine <LayoutId>, <LayoutFormatMode>, <LayoutData>
DISPlay:LAYout:DEFine? <LayoutId>
Creates a horizontal or vertical display layout and provides it with an identifier (<Layou-
tId>).
