out. The <RepeatFormat> descriptors can be nested in order to describe joined
layouts; refer to Creating Diagrams for an easy example.
●
For a horizontal layout with N rows, each of height h
i
(i = 1 ... N) and filled with M(i)
diagrams with independent widths w
ij
(j = 1, 2 ...M(i)), the data string is composed
as follows:
<StartFormat> = N,1,0.00,0.00
<RepeatFormat
i
> = (1,M(i),1.00,h
i
[w
i1
,1.00], [w
i2
,1.00] ... [w
iM(i)
,1.00])
●
For a vertical layout with N columns, each of width w
i
(i = 1 ... N) and filled with M(i)
diagrams with independent heights h
ij
(j = 1, 2 ...M(i)), the data string is composed
as follows:
<StartFormat> = 1,N,0.00,0.00
<RepeatFormat
i
> = (M(i),1,w
i
,1.00,[1.00,h
i1
], [1.00,h
i2
] ... [1.00,h
iM(i)
])
Note: The maximum number of diagrams in a layout is 256.
Parameters:
<LayoutData> String parameter defining the number of diagrams and their
position (executable format); see above.
Example: See Creating Diagrams
Manual operation: See "Additional Functionality: SCPI Commands" on page 687
DISPlay:LAYout:GRID <Rows>, <Columns>
Defines the number of rows and columns if DISPlay:LAYout GRID is set.
Parameters:
<Rows> Range: 1 to 16
*RST: 1
<Columns> Range: 1 to 16
*RST: 1
Example:
DISPlay:LAYout GRID
Select te split type where the diagrams are arranged in rows and
columns.
DISPlay:LAYout:GRID 2,2
Arrange 4 diagrams in two rows and two columns.
Manual operation: See "Diagrams / Rows / Columns" on page 687
DISPlay:LAYout:JOIN <MainLayoutId>, <DiagramNumber>, <SubLayoutId>
Creates a nested layout, inserting a sub-layout into one of the diagrams of a main lay-
out. Main layout and sub-layout must be defined previously, preferably using
DISPlay:LAYout:DEFine.
Note: The maximum number of joined levels within a layout is 16.
