Query parameters:
<ConnectorType> Name of the connector type. Use [SENSe<Ch>:
]CORRection:CONNection:CATalog? to query connector
names.
<CalKitName> String parameter containing the name of the calibration kit. See
"Cal kit naming conventions " under [SENSe:]CORRection:
CKIT:<ConnType>:LSELect.
<KitLabel> String parameter containing the label of the calibration kit, usu-
ally the serial number.
<StandardType> MMTHrough | MFTHrough | FFTHrough | MMLine | MMLine1 |
MMLine2 | MMLine3 | MFLine | MFLine1 | MFLine2 | MFLine3 |
FFLine | FFLine1 | FFLine2 | FFLine3 | MMATten | MFATten |
FFATten | MMSNetwork | MFSNetwork | FFSNetwork | MOPen |
FOPen | MSHort | FSHort | MOSHort | MOSHort1 | MOSHort2 |
MOSHort3 | FOSHort | FOSHort1 | FOSHort2 | FOSHort3 |
MREFlect | FREFlect | MMTCh | FMTCh | MSMatch | FSMatch
Standard type; see Table 8-14
<DelayMode> DELay | ELENgth
ELENgth (default) – ZVR compatible modelling
DELay – Agilent modelling
<Port1>[, <Port2>] Optional port restriction: one port number for one port standards,
two port numbers for two port standards
Usage: Query only
[SENSe:]CORRection:CKIT:<ConnType>:SELect <CalKitName>
Selects the calibration kit to be used for a specified connector type <ConnType>. The
kit is identified by its name.
Tip: For connector types with arbitrary, user-defined names you can use the command
[SENSe:]CORRection:CKIT:SELect.
Cal kit naming conventions
Calibration kit names must be entered as string parameters. The string contains the cal
kit name used in the calibration dialogs (e.g. "Calibration Presettings"); a "Ω" in the
name must be replaced by Ohm, e.g.:
●
NewKit1 denotes the user-defined calibration kit "NewKit1".
●
N 50 Ohm Ideal Kit denotes the "N 50 Ω Ideal Kit".
●
ZV-Z21 typical denotes the cal kit "ZV-Z21 typical".
Suffix:
<ConnType>
.
Connector type, one of the following identifiers:
N50, N75 – N 50 Ω or N 75 Ω connectors
PC7, PC35, PC292 – PC 7, PC 3.5 or 2.92 mm connectors
USER<no> – user-defined connectors UserConn1, UserConn2
SMA – user-defined connector type SMA ...
