R&S ZNB - Page 1171

Command Reference
R&S
®
ZNB/ZNBT
1171User Manual 1173.9163.02 ─ 55
Suffix:
<Ch>
.
Channel number of the offset-corrected channel
<PhyPt> Port number of the analyzer
Parameters:
<Permittivity> Permittivity
Range: 1 to +1E+6
*RST: 1.00062
Example: See [SENSe<Ch>:]CORRection:EDELay<PhyPt>:ELENgth
Manual operation: See "Permittivity / Velocity Factor" on page 580
[SENSe<Ch>:]CORRection:EDELay<PhyPt>:DISTance
<MechLength>
Defines the offset parameter for test port <PhyPt> as a mechanical length.
Suffix:
<Ch>
.
Channel number of the offset-corrected channel
<PhyPt> Port number of the analyzer
Parameters:
<MechLength> Mechanical length
Range: -3.402823466E+038 m to +3.4028234664E+038 m.
*RST: 0 m
Default unit: m
Example: See [SENSe<Ch>:]CORRection:EDELay<PhyPt>:ELENgth
Manual operation: See "Delay / Electrical Length / Mech. Length" on page 579
[SENSe<Ch>:]CORRection:EDELay<PhyPt>:ELENgth <ElecLength>
Defines the offset parameter for test port <PhyPt> as an electrical length.
Suffix:
<Ch>
.
Channel number of the offset-corrected channel
<PhyPt> Port number of the analyzer
Parameters:
<ElecLength> Electrical length
Range: -1E+9 m to +1E+9 m.
Increment: 1 mm
*RST: 0 m
Default unit: m
SCPI Command Reference
