Parameters:
<Resistance> Range: 0 Ohm to 1E+9 Ohm
*RST: 50 Ohm
Default unit: Ohm
Example: See [SENSe<Ch>:]PAE:TYPE
Manual operation: See "Formula" on page 288
[SENSe<Ch>:]PAE:PARameters:U <Voltage>
Defines the constant DC supply voltage U
0
for the PAE measurement (measurement
type "Constant Voltage Source"; see example).
Suffix:
<Ch>
.
Channel number
Parameters:
<Voltage> *RST: 0 V
Default unit: V
Example: See [SENSe<Ch>:]PAE:TYPE
Manual operation: See "Formula" on page 288
[SENSe<Ch>:]PAE:TYPE <Type>
Selects the measurement type for the Power Added Efficiency (PAE) measurement.
The three measurement types involve different test setups, input parameters, and DC
voltage measurements.
Suffix:
<Ch>
.
Channel number
Parameters:
<Type> VOLTage | CURRent | VCURrent
Constant voltage source, constant current source, voltage and
current
*RST: VOLTage
