Example:
SOURce:POWer:SWEepend:MODE REDuce
Reduce power at sweep end.
SOURce:POWer:SWEepend:SDELay 0.01
Use a settling delay of 10 ms
SOURce:POWer:SWEepend:MODE AUTO
At sweep end, restore the power at sweep start
Manual operation: See "Power Mode at Sweep End" on page 708
SOURce:POWer:SWEepend:SDELay <SettlingDelay>
If sweep end mode REDuce or KEEP is active (see SOURce:POWer:SWEepend:
MODE) this defines the settling delay at subsequent sweep starts, i.e. the time between
power reset and sweep start when a new sweep is requested.
This is a global setting.
Parameters:
<SettlingDelay> Settling delay
Default unit: s
Manual operation: See "Settling Delay / Reset Delay" on page 709
SOURce<Ch>:POWer<PhyPt>[:LEVel][:IMMediate][:AMPLitude] <IntSourcePow>
Defines the power of the internal signal source (channel base power). The setting is
valid for all sweep types, except power sweep.
Tip: Use SOURce<Ch>:POWer<PhyPt>:STARt and SOURce<Ch>:POWer<PhyPt>:
STOP to define the sweep range for a power sweep.
Suffix:
<Ch>
.
Channel number
<PhyPt> Test port number of the analyzer. This suffix is ignored because
the selected channel base power applies to all source ports
used in the active channel.
It is possible though to define a port-specific slope factor for the
source power (SOURce<Ch>:POWer<PhyPt>[:LEVel][:
IMMediate]:SLOPe) and a port-specific power offset
(SOURce<Ch>:POWer<PhyPt>[:LEVel][:IMMediate]:
OFFSet).
Parameters:
<IntSourcePow> Internal source power
Range: The usable power range is frequency-dependent;
refer to the data sheet.
*RST: -10 dBm
Default unit: dBm
