Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1319)
Setting parameters:
<Matrix VNA Port
Label>
These labels are specified in the corresponding matrix driver file
(see SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:
DEFine on page 1319).
<VNA Port Number>
Range: 1 ... # of RF ports of the VNA
Example: A switch matrix ZV-Z84-02 is used.
SYSTem:COMMunicate:RDEVice:SMATrix1:CONFigure:
MLVNA '1A',1,'2B',2
VNA ports 1 and 2 are connected to matrix VNA ports '1A' and
'2B', respectively
Manual operation: See "Edit Matrix VNA Port Connections" on page 736
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MLTest {<Matrix Test
Port Label>, <TPNumber>}
Sets/gets the matrix test port connections. Similar to SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:CONFigure:MTESt, but uses the front panel labels of
the matrix test ports instead.
By default, these labels are only available for some matrix types.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1319)
Setting parameters:
<Matrix Test Port
Label>
If available, these labels are specified in the corresponding
matrix driver file (see SYSTem:COMMunicate:RDEVice:
SMATrix<Matr>:DEFine on page 1319).
<Test Port Number> Test ports must be numbered subsequently, starting at 1.
Example: A switch matrix ZV-Z82-16 is used.
SYSTem:COMMunicate:RDEVice:SMATrix1:CONFigure:
MLTESt 'A1',1,'B1',2
The first test ports of submatrices A and B are assigned to test
ports 1 and 2, respectively.
