Command Reference
R&S
®
ZNB/ZNBT
1357User Manual 1173.9163.02 ─ 55
Setting parameters:
<TraceName> Trace name, e.g. 'Trc4'. See "Rules for trace names" in "Table
Area" on page 305.
<Result> S11 | S12 | S13 | S14 | S21 | S22 | S23 | S24 | S31 | S32 | S33 |
S34 | S41 | S42 | S43 | S44 | A | B | C | D | R1 | R2 | R3 | R4 |
AB | AC | AD | BA | BC | BD | CA | CB | CD | DA | DB | DC |
AR1 | AR2 | AR3 | AR4 | BR1 | BR2 | BR3 | BR4 | CR1 | CR2 |
CR3 | CR4 | DR1 | DR2 | DR3 | DR4 | R1A | R1B | R1C | R1D |
R2A | R2B | R2C | R2D | R3A | R3B | R3C | R3D | R4A | R4B |
R4C | R4D | R1R2 | R1R3 | R1R4 | R2R1 | R2R3 | R2R4 |
R3R1 | R3R2 | R3R4 | R4R1 | R4R2 | R4R3
Measurement parameter; see list of parameters below.
<TestPortNum> Test port number, drive port for wave quantities and ratios,
ignored for S-parameters.
Example:
CALC4:PAR:DEF 'Ch4Tr1', S11
Create channel 4 and a trace named Ch4Tr1 to measure the
input reflection coefficient S11.
DISP:WIND:STAT ON
Create diagram area no. 1.
DISP:WIND:TRAC2:FEED 'CH4TR1'
Display the generated trace in diagram area no. 1, assigning a
trace number 2.
Usage: Setting only
The measurement parameter is selected by means of the following keywords (the
selection depends on the number of test ports of the analyzer, e.g. S44 is not available
on 2-port analyzers):
S11 | S12 | S13 | S14 | S21 | S22 | S23 | S24 | S31 |
S32 | S33 | S34 | S41 | S42 | S43 | S44
S-parameters
A | B | C | D Wave quantities b
1
, b
2
, b
3
, b
4
(received waves)
R1 | R2 | R3 | R4 Wave quantities a
1
, a
2
, a
3
, a
4
(reference waves)
AB | AC | AD | BA | BC | BD | CA | CB | CD | DA | dB
| DC
Ratio of wave quantities b
1
/b
2
, b
1
/b
3
, ... , b
4
/b
3
(received waves only)
AR1 | AR2 | AR3 | AR4 | BR1 | BR2 | BR3 | BR4 |
CR1 | CR2 | CR3 | CR4 | DR1 | DR2 | DR3 | DR4 |
R1A | R1B | R1C | R1D | R2A | R2B | R2C | R2D |
R3A | R3B | R3C | R3D | R4A | R4B | R4C | R4D
Ratio of wave quantities b
1
/a
1
, b
1
/a
2
, ... , b
4
/a
4
, a
1
/b
1
,
a
1
/b
2
, ..., A
4
/B
4
(received waves to reference waves
or reference waves to received waves)
R1R2 | R1R3 | R1R4 | R2R1 | R2R3 | R2R4 | R3R1
| R3R2 | R3R4 | R4R1 | R4R2 | R4R3
Ratio of wave quantities a
1
/a
2
, a
1
/a
3
, ... , a
4
/a
3
(refer-
ence waves only)
CALCulate<Chn>:MARKer<Mk>:FUNCtion:BWIDth <Bandwidth>
Defines the bandfilter level, i.e. the minimum excursion for the bandpass and bandstop
peaks.
