CALCulate<Chn>:EYE:JITTer:TYPE:USER <Boolean>
Enables/disables user-defined jitter insertion in the generator simulation of the related
eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Prior to enabling user-defined jitter, the jitter values must have been loaded from file
using MMEMory:LOAD:EYE:JITTer.
Note that jitter will not be applied unless the jitter functionality is activated using
CALCulate<Chn>:EYE:JITTer:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "User Specific" on page 647
CALCulate<Chn>:EYE:MASK AUTO
Automatically creates an eye mask, based on the current eye measurement settings.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Usage: Setting only
Manual operation: See "Automatic Mask Generation" on page 654
CALCulate<Chn>:EYE:MASK:CENTer:HORizontal <HorizontalOffset>
Defines the horizontal center of the eye mask in the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<HorizontalOffset> Horizontal offset relative to the middle of the eye diagram
Default unit: s
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Mask Center" on page 653
CALCulate<Chn>:EYE:MASK:CENTer:VERTical <VerticalOffset>
Defines the vertical center of the eye mask in the related eye diagram.
