Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<StdDeviation> Default unit: s
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Random" on page 646
CALCulate<Chn>:EYE:JITTer:STATe <Boolean>
Activates the jitter functionality in the generator simulation of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
The individual jitter sources can be selectively enabled using
●
CALCulate<Chn>:EYE:JITTer:TYPE:DIRac
●
CALCulate<Chn>:EYE:JITTer:TYPE:PERiodic
●
CALCulate<Chn>:EYE:JITTer:TYPE:RANDom
●
CALCulate<Chn>:EYE:JITTer:TYPE:USER
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Active" on page 646
CALCulate<Chn>:EYE:JITTer:TYPE:DIRac <Boolean>
Enables/disables Dirac jitter insertion in the generator simulation of the related eye dia-
gram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Amplitude and probability of the jitter can be specified using CALCulate<Chn>:EYE:
JITTer:DIRac:DELTa and CALCulate<Chn>:EYE:JITTer:DIRac:
PROBability, respectively.
Note that jitter will not be applied unless the jitter functionality is activated using
CALCulate<Chn>:EYE:JITTer:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
