R&S ZNB User Manual

Command Reference
R&S
®
ZNB/ZNBT
811User Manual 1173.9163.02 ─ 55
Use CALCulate<Chn>:EYE:MASK:SHAPe:BOTTom:STATe or CALCulate<Chn>:
EYE:MASK:SHAPe:TOP:STATe to activate or deactivate the area in the eye mask.
The eye mask test is enabled/disabled using CALCulate<Chn>:EYE:MASK:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Offset> Default unit: V
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Top/Bottom Setup" on page 653
CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:TYPE <PolygonType>
Defines the shape of the center polygon (octagon, hexagon or rectangle) in the eye
mask of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Use CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:STATe to activate or deacti-
vate the area in the eye mask. The eye mask test is enabled/disabled using
CALCulate<Chn>:EYE:MASK:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<PolygonType> OCTogon | HEXagon | RECTangle
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Polygon Setup" on page 652
CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:HORizontal <Main>[, <Minor>]
Defines the main [and minor] width of the center polygon in the mask of the related eye
diagram. The geometric interpretation depends on the selected polygon type (see
CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:TYPE on page 811):
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Use CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:STATe to activate or deacti-
vate the center polygon in the eye mask. The eye mask test is enabled/disabled using
CALCulate<Chn>:EYE:MASK:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Main> Default unit: s
<Minor> Default unit: s
