The one-length method (CALCulate:FMODel:DELT<Ph_pt>:METHod M1L) handles
single-ended and balanced measurement results differently.
Suffix:
<Ph_pt>
.
This suffix is ignored
Parameters:
<Measurement> SINGleended | BALanced
SINGleended
Single-ended or balanced analysis
BALanced
Balanced analysis
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Measurements" on page 613
CALCulate:FMODel:DELT<Ph_pt>:METHod
<Method>
Selects the Delta-L+ characterization method to be used.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<Method> M1L | M2L | M3L
One, two, or three line/length analysis
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Method" on page 613
CALCulate:FMODel:DELT<Ph_pt>:PORDer <PortOrder>
Declares how the DUT is connected to the measurement system. Choosing the wrong
port ordering for your setup, can result in erroneous results.
Suffix:
<Ph_pt>
.
This suffix is ignored
Parameters:
<PortOrder> ODDeven | SEQuential
ODDeven
Ports 1, 3 and 2, 4 form input/output pairs
SEQuential
Ports 1, 2 and 3, 4 form input/output pairs
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Port Order" on page 613
