CALCulate<Chn>:LIMit:CONTrol:SHIFt <LimShift>
Shifts an existing limit line in horizontal direction. See also Chapter 5.4.1.1, "Rules for
Limit Line Definition", on page 133.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Setting parameters:
<LimShift> Offset value for the limit line
Range: Virtually no restriction for limit segments
Default unit: NN
Example:
*RST; :CALC:LIM:CONT 1 GHZ, 2 GHZ
Define a limit line segment in the stimulus range between 1 GHz
and 2 GHz, using default response values.
CALC:LIM:CONT:SHIF 1; :CALC:LIM:CONT?
Shift the segment by 1 Hz. The modified limit line segment
ranges from 1000000001 (Hz) to 2000000001 (Hz).
Usage: Setting only
Manual operation: See "Shift Lines" on page 345
CALCulate<Chn>:LIMit:DATA <Type>, <StartStim>, <StopStim>, <StartResp>,
<StopResp>
Defines the limit line type, the stimulus and response values for a limit line with an arbi-
trary number of limit line segments. See Chapter 5.4.1.1, "Rules for Limit Line Defini-
tion", on page 133.
Note: In contrast to CALCulate<Chn>:LIMit:CONTrol[:DATA], this command
does not overwrite existing limit line segments. The defined segments are appended to
the segment list as new segments.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Type> Identifier for the type of the limit line segment:
0 – limit line segment off, segment defined but no limit check
performed.
1 – upper limit line segment
2 – lower limit line segment
Range: 0, 1, 2 (see above)
<StartStim>,
<StopStim>,
<StartResp>,
<StopResp>
Stimulus and response values of the first and last points of the
limit line segment.
The unit of the stimulus values is adjusted to the sweep type of
the active channel ([SENSe<Ch>:]SWEep:TYPE), the unit of
the ripple limit is adjusted to the format of the active trace
(CALCulate<Chn>:FORMat).
