CALCulate<Chn>:STATistics:EPDelay[:STATe] <Boolean>
CALCulate<Chn>:STATistics:MMPTpeak[:STATe] <Boolean>
CALCulate<Chn>:STATistics:MSTDdev[:STATe] <Boolean>
These commands display or hide the "Phase/El Length" results, the "Min/Max/Peak-
Peak" results, and the "Mean/Std Dev" results in the diagram area of trace no. <Chn>.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> ON | OFF - statistical info field on or off.
*RST: OFF
Example: See CALCulate<Chn>:STATistics[:STATe]
Manual operation: See "Min/Max/Peak-Peak, Mean/Std Dev/RMS" on page 324
CALCulate<Chn>:STATistics:FORMat
<Format>
For complex-valued traces (Smith, Polar) this determines how the MEAN, STDDev,
MAX, MIN, RMS and PTPeak statistics are calculated, see CALCulate<Chn>:
STATistics:RESult?.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Format> ZVAB | IMPedance | ADMittance
ZVAB
The results are based on unformatted wave quantities (voltages)
IMPedance
The results are based on resistance values
ADMittance
The results are based on conductance vaules
Manual operation: See "Format" on page 325
CALCulate<Chn>:STATistics:NLINear:COMP:LEVel <dBValue>
Defines the compression value x for the compression point measurement for dB for-
matted traces.
Use CALCulate<Chn>:STATistics:NLINear:COMP:RESult? to retrieve the
compression results.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
dBValue Compression value
