Example:
*RST; :CALC:PAR:SDEF 'Trc2', 'S11'
Create a trace named Trc2.
CONF:TRAC:WIND:TRAC? 'Trc2'
Query the diagram number for Trc2. The new trace is not dis-
played, so the response is 0.
DISP:WIND2:STAT ON
Create a diagram no. 2.
DISP:WIND2:TRAC3:FEED 'Trc2'
Display the trace in the new diagram no. 2, assigning the trace
number 3.
CONF:TRAC:WIND? 'Trc2'
Query the diagram number for Trc2. The response is 2.
CONF:TRAC:WIND:TRAC? 'Trc2'
Query the trace number for Trc2. The response is 3.
Usage:
Query only
Manual operation: See "Table Area" on page 305
CONFigure:TRACe<Trc>:CHANnel:NAME?
<TraceName>
Queries the channel name for an existing trace named '<TraceName>'.
Suffix:
<Trc>
.
Trace number. This suffix is ignored; the trace is referenced by
its name.
Query parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
Example: See CONFigure:TRACe:CATalog?
Usage: Query only
Manual operation: See "New Channel" on page 511
CONFigure:TRACe<Trc>:CHANnel:NAME:ID? <TraceName>
Queries the channel number (numeric suffix) for an existing trace named
'<TraceName>'.
Suffix:
<Trc>
.
Trace number. This suffix is ignored; the trace is referenced by
its name.
Query parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
Example: See CONFigure:TRACe:CATalog?
Usage: Query only
Manual operation: See "New Channel" on page 511
