Command Reference
R&S
®
ZNB/ZNBT
994User Manual 1173.9163.02 ─ 55
Example:
*RST; :CALC2:PAR:SDEF 'Ch2Trc2', 'S11'
Create channel 2 and a new trace named Ch2Trc2.
CONF:TRAC:CAT?
Query all traces and their names. As a default trace no. 1 is cre-
ated upon *RST, the response is '1,Trc1,2,Ch2Trc2'.
CONF:CHAN1:TRAC:CAT?
Query the channels in channel no. 1. The response is
'1,Trc1'.
CONF:TRAC:NAME:ID? 'Ch2Trc2'
Query the trace number for the trace named "Ch2Trc2". The
response is 2.
CONF:TRAC2:NAME?
Query the trace name for trace no. 2. The response is
'Ch2Trc2'.
CONF:TRAC:CHAN:NAME? 'Ch2Trc2'
Query the channel name for trace Ch2Trc2. The response is
'Ch2'.
CONF:TRAC:CHAN:NAME:ID? 'Ch2Trc2'
Query the channel number for trace Ch2Trc2. The response is
2.
Usage:
Query only
Manual operation: See "Table Area" on page 305
CONFigure:TRACe:WINDow? <TraceName>
Returns the trace number within a diagram which is assigned to the trace
<TraceName> is assigned to. A zero is returned when the trace is not assigned/
displayed.
The trace number is equal to the <WndTr> suffix in DISPlay[:WINDow<Wnd>]:
TRACe<WndTr>:FEED and similiar commands; see example.
Query parameters:
<TraceName> Trace name (string), e.g. 'Trc1'
Example: See CONFigure:TRACe:WINDow:TRACe?
Usage: Query only
CONFigure:TRACe:WINDow:TRACe? <TraceName>
Returns the number of the diagram which the trace <TraceName> is assigned to. A
zero is returned when the trace is not assigned/displayed.
The diagram number is equal to the <Wnd> suffix in DISPlay[:WINDow<Wnd>]:
TRACe<WndTr>:FEED and similar commands; see example.
Query parameters:
<TraceName> Trace name (string), e.g. 'Trc1'
