PM TABLES
B234/B235/B236/D101/D102/D103 2-10 SM
500K 1000K Note
PAPER FEED
Paper feed rollers x3 R
Pick-up rollers x3 R
Separation rollers x3 R
Replace together.
Grip rollers C
Damp cloth
Relay rollers C
Damp cloth
Paper feed guide plate I
Damp cloth
Upper and lower registration rollers C
Damp cloth
Registration sensor C
Blower brush
Relay sensor C
Blower brush
Paper dust remover C
Remove paper dust.
Paper feed sensors C
Blower brush
DUPLEX UNIT 500K Note
Transport rollers C
Feed rollers C
Reverse transport roller C
Reverse feed roller C
Inverter feed rollers C
Inverter transport rollers C
Damp cloth
Entrance sensor C
Anti-static brush I
Blower brush
Duplex inverter sensor C
Blower brush, inspect feeler
movement.
Duplex transport sensor C Blower brush
Horizontal transport feed roller (resin roller) C Damp cloth
GW
CONTROLLER
500K
Controller filter C Blower brush
PSU 500K
PSU filter C Blower brush
Exterior 500K
Heat pipe cooling fan suction duct C Blower brush
OTHERS 1 Year
Breaker
switches
I Test the operation of the two breaker switches (main body,
z-folder) once every year.
