Common Procedures
SM 3-9 B234/B235/B236/D101/D102/D103
Replacement
Adjustment
4. In this order:
• Attach knob n
• Fasten screw o
• Gently rotate lever C1 p up.
5. Reattach the ground plate ( x1).
6. Mount the inner cover.
• Attach screw n first but do not tighten.
• Attach the other screws.
• Tighten all the screws.
7. Close the right front door.
3
1
2
B234R918.WMF
B234I110E.WMF
2
2
2
1
B234R920.WMF
To Next Page
