31.17.10 Example of configuration
● Set the bit TRCENA in the Debug Exception and Monitor Control Register (DEMCR)
● Write the TPIU Current Port Size Register to the desired value (default is 0x1 for a 1-bit
port size)
● Write TPIU Formatter and Flush Control Register to 0x102 (default value)
● Write the TPIU Select Pin Protocol to select the sync or async mode. Example: 0x2 for
async NRZ mode (UART like)
● Write the DBGMCU control register to 0x20 (bit IO_TRACEN) to assign TRACE IOs for
async mode. A TPIU Sync packet is emitted at this time (FF_FF_FF_7F)
● Configure the ITM and write the ITM Stimulus register to output a value
31.18 DBG register map
The following table summarizes the Debug registers.
Table 231. DBG register map and reset values
Addr. Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0xE0042000
DBGMCU_
IDCODE
REV_ID
Reserved
DEV_ID
Reset value
(1)
XXXXXXXXXXXXXXXX XXXXXXXXXXXX
0xE0042004
DBGMCU_CR
Reserved
DGB_CAN2_STOP
DBG_TIM7_STOP
DBG_TIM6_STOP
DBG_TIM5_STOP
DBG_TIM8_STOP
DBG_I2C2_SMBUS_TIMEOUT
DBG_I2C1_SMBUS_TIMEOUT
DBG_CAN1_STOP
DBG_TIM4_STOP
DBG_TIM3_STOP
DBG_TIM2_STOP
DBG_TIM1_STOP
DBG_WWDG_STOP
DBG_IWDGSTOP
TRACE_MODE[1:0]
TRACE_IOEN
Reserved
DBG_STANDBY
DBG_STOP
DBG_SLEEP
Reset value 00000000000000000 000
1. The reset value is product dependent. For more information, refer to Section 31.6.1: MCU device ID code.
