RM0008 Debug support (DBG)
Doc ID 13902 Rev 12 1073/1096
TPUI TRACE pin assignment
By default, these pins are NOT assigned. They can be assigned by setting the
TRACE_IOEN and TRACE_MODE bits in the MCU Debug component configuration
register. This configuration has to be done by the debugger host.
In addition, the number of pins to assign depends on the trace configuration (asynchronous
or synchronous).
● Asynchronous mode: 1 extra pin is needed
● Synchronous mode: from 2 to 5 extra pins are needed depending on the size of the
data trace port register (1, 2 or 4):
– TRACECK
– TRACED(0) if port size is configured to 1, 2 or 4
– TRACED(1) if port size is configured to 2 or 4
– TRACED(2) if port size is configured to 4
– TRACED(3) if port size is configured to 4
To assign the TRACE pin, the debugger host must program the bits TRACE_IOEN and
TRACE_MODE[1:0] of the Debug MCU configuration Register (DBGMCU_CR). By default
the TRACE pins are not assigned.
This register is mapped on the external PPB and is reset by the PORESET (and not by the
SYSTEM reset). It can be written by the debugger under SYSTEM reset.
Table 228. Synchronous TRACE pin assignment
TPUI pin name
Trace synchronous mode
STM32F10xxx pin
assignment
Type Description
TRACECK O TRACE Clock PE2
TRACED[3:0] O
TRACE Sync Data Outputs
Can be 1, 2 or 4.
PE[6:3]
