General-purpose timers (TIM9 to TIM14) RM0008
450/1096 Doc ID 13902 Rev 12
16.6.10 TIM10/11/13/14 capture/compare register 1 (TIMx_CCR1)
Address offset: 0x34
Reset value: 0x0000
16.6.11 TIM10/11/13/14 register map
TIMx registers are mapped as 16-bit addressable registers as described in the tables below:
1514131211109876543210
CCR1[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0 CCR1[15:0]: Capture/Compare 1 value
If channel CC1 is configured as output:
CCR1 is the value to be loaded in the actual capture/compare 1 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register (bit
OC1PE). Else the preload value is copied in the active capture/compare 1 register when an
update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on OC1 output.
If channel CC1is configured as input:
CCR1 is the counter value transferred by the last input capture 1 event (IC1).
Table 93. TIM10/11/13/14 register map and reset values
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0x00
TIMx_CR1
Reserved
CKD
[1:0]
ARPE
Reserved
Reserved
Reserved
Reserved
URS
UDIS
CEN
Reset value 000 000
0x08
TIMx_SMCR
Not Available
Reset value
0x0C
TIMx_DIER
Reserved
CC1IE
UIE
Reset value 00
0x10
TIMx_SR
Reserved
CC1OF
Reserved
CC1IF
UIF
Reset value 000
0x14
TIMx_EGR
Reserved
CC1G
UG
Reset value 00
0x18
TIMx_CCMR1
Output compare
mode
Reserved
OC1M
[2:0]
OC1PE
OC1FE
CC1S
[1:0]
Reset value 0000000
TIMx_CCMR1
Input capture
mode
Reserved
IC1F[3:0]
IC1
PSC
[1:0]
CC1S
[1:0]
Reset value 00000000
0x1C
Reserved
0x20
TIMx_CCER
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
CC1NP
Reserved
CC1P
CC1E
Reset value 000
