RM0008 General-purpose timers (TIM9 to TIM14)

Doc ID 13902 Rev 12 451/1096

Refer to Table 3 on page 50 for the register boundary addresses.

0x24

TIMx_CNT

Reserved

CNT[15:0]

Reset value 0000000000000000

0x28

TIMx_PSC

Reserved

PSC[15:0]

Reset value 0000000000000000

0x2C

TIMx_ARR

Reserved

ARR[15:0]

Reset value 0000000000000000

0x30

Reserved

0x34

TIMx_CCR1

Reserved

CCR1[15:0]

Reset value 0000000000000000

0x38 to

0x4C

Reserved

Table 93. TIM10/11/13/14 register map and reset values (continued)

Offset Register
