Controller area network (bxCAN) RM0008
660/1096 Doc ID 13902 Rev 12
24.9.3 CAN mailbox registers
This chapter describes the registers of the transmit and receive mailboxes. Refer to
Section 24.7.5: Message storage on page 644 for detailed register mapping.
Transmit and receive mailboxes have the same registers except:
● The FMI field in the CAN_RDTxR register.
● A receive mailbox is always write protected.
● A transmit mailbox is write-enabled only while empty, corresponding TME bit in the
CAN_TSR register set.
There are 3 TX Mailboxes and 2 RX Mailboxes. Each RX Mailbox allows access to a 3 level
depth FIFO, the access being offered only to the oldest received message in the FIFO.
Each mailbox consist of 4 registers.
Bits 25:24 SJW[1:0]: Resynchronization jump width
These bits define the maximum number of time quanta the CAN hardware is allowed to
lengthen or shorten a bit to perform the resynchronization.
t
RJW
= t
CAN
x (SJW[1:0] + 1)
Bit 23 Reserved, forced by hardware to 0.
Bits 22:20 TS2[2:0]
: Time segment 2
These bits define the number of time quanta in Time Segment 2.
t
BS2
= t
CAN
x (TS2[2:0] + 1)
Bits 19:16 TS1[3:0]
: Time segment 1
These bits define the number of time quanta in Time Segment 1
t
BS1
= t
CAN
x (TS1[3:0] + 1)
For more information on bit timing, please refer to Section 24.7.7: Bit timing on page 646.
Bits 15:10 Reserved, forced by hardware to 0.
Bits 9:0 BRP[9:0]
: Baud rate prescaler
These bits define the length of a time quanta.
t
q
= (BRP[9:0]+1) x t
PCLK
CAN_RI0R
CAN_RDT0R
CAN_RL0R
CAN_RH0R
CAN_TI0R
CAN_TDT0R
CAN_TDL0R
CAN_TDH0R
FIFO0
Three Tx Mailboxes
CAN_RI1R
CAN_RDT1R
CAN_RL1R
CAN_RH1R
FIFO1
CAN_TI1R
CAN_TDT1R
CAN_TDL1R
CAN_TDH1R
CAN_TI2R
CAN_TDT2R
CAN_TDL2R
CAN_TDH2R
