Page #709 background image
RM0008 Serial peripheral interface (SPI)
Doc ID 13902 Rev 12 709/1096
Table 184. Audio-frequency precision using standard 14.7456 MHz and PLL3
(connectivity line
devices only)
Data
length
PREDIV2 PLL3MUL I2SDIV I2SODD MCLK
Targ et
fs(Hz)
Real fs
(KHz)
Error
16 3 10 16 0 No 96000 96000 0.0000%
32 3 10 8 0 No 96000 96000 0.0000%
16 3 10 32 0 No 48000 48000 0.0000%
32 3 10 16 0 No 48000 48000 0.0000%
16 4 9 23 1 No 44100 44119.148 0.0434%
32 4 13 17 0 No 44100 44047.059 0.1200%
16 3 10 48 0 No 32000 32000 0.0000%
32 3 10 24 0 No 32000 32000 0.0000%
16 4 20 104 1 No 22050 22047.8469 0.0098%
32 4 9 32 1 No 22050 22059.5745 0.0434%
16 3 10 96 0 No 16000 16000 0.0000%
32 3 10 48 0 No 16000 16000 0.0000%
16 4 20 209 1 No 11025 11023.923 0.0098%
32 4 20 104 1 No 11025 11023.923 0.0098%
16 3 10 192 0 No 8000 8000 0.0000%
32 3 10 96 0 No 8000 8000 0.0000%
16 3 10 2 0 Yes 96000 96000 0.0000%
32 3 10 2 0 Yes 96000 96000 0.0000%
16 3 10 4 0 Yes 48000 48000 0.0000%
32 3 10 4 0 Yes 48000 48000 0.0000%
16 4 20 6 1 Yes 44100 44307.6923 0.4710%
32 4 20 6 1 Yes 44100 44307.6923 0.4710%
16 3 10 6 0 Yes 32000 32000 0.0000%
32 3 10 6 0 Yes 32000 32000 0.0000%
16 4 13 8 1 Yes 22050 22023.5294 0.1200%
32 4 13 8 1 Yes 22050 22023.5294 0.1200%
16 3 10 12 0 Yes 16000 16000 0.0000%
32 3 10 12 0 Yes 16000 16000 0.0000%
16 4 13 17 0 Yes 11025 11029.7872 0.0434%
32 4 13 17 0 Yes 11025 11029.7872 0.0434%
16 3 10 24 0 Yes 8000 8000 0.0000%
32 3 10 24 0 Yes 8000 8000 0.0000%
