Revision history RM0008
1088/1096 Doc ID 13902 Rev 12
22-Jun-2009 9
Reference manual updated to support also STM32F105xx/STM32F107xx connectivity line
devices.
Memory and bus architecture section: Embedded boot loader updated.
Section 4.3: CRC functional description updated.
Note modified in Section 5.1.2: Battery backup domain.
Connectivity line devices: reset and clock control (RCC) section: Figure 10: Simplified
diagram of the reset circuit updated. PLL1 changed to PLL. Note added to BDP bit
description in Section 5.4.1: Power control register (PWR_CR). Table 57: SPI3/I2S3
remapping corrected.
DMA section: Table 76: Programmable data width & endian behavior (when bits PINC =
MINC = 1) updated, Section 13.3.1: DMA transactions and Pointer incrementation on
page 266 modified. DMA channel x peripheral address register (DMA_CPARx) (x = 1..7),
where x = channel number) and DMA channel x memory address register (DMA_CMARx)
(x = 1..7), where x = channel number) must not be written when the channel is enabled.
Advanced-control timer section: Section 14.3.12: Using the break function on page 306
updated. BKE and BKP bit descriptions updated in Section 14.4.18: TIM1&TIM8 break and
dead-time register (TIMx_BDTR). CC1IF bit description modified in Section 14.4.5:
TIM1&TIM8 status register (TIMx_SR) and Section 15.4.5: TIMx status register
(TIMx_SR).
Note added to Table 82: TIMx Internal trigger connection and Table 86: TIMx Internal
trigger connection on page 388.
Table 107: NOR Flash/PSRAM supported memories and transactions on page 497 and
Single-burst transfer modified.
Register numbering and address offset corrected in Section 22.9.6: SDIO response 1..4
register (SDIO_RESPx) on page 585.
In Section 24: Controller area network (bxCAN): DBF bit reset value and access type
modified, small text changes.
SPI section: note added in Section 25.2.2: I2S features. Slave select (NSS) pin
management clarified. Note added at the end of Section 25.3.3: Configuring the SPI in
master mode and Section 25.3.4: Configuring the SPI for Simplex communication.
Audio frequency precision tables 183 and 184 added to Section 25.4.3: Clock generator on
page 705 and audio sampling frequency range increased to 96 kHz.
Arbitration lost (ARLO) on page 740 specified.
USART section: Description of “1.5 stop bits” updated in Configurable stop bits,
RTS flow
control corrected. Procedure sequence modified in Section 27.3.2: Transmitter. How to
derive USARTDIV from USART_BRR register values modified. Section 27.3.5: USART
receiver’s tolerance to clock deviation added. Section 27.3.11: Smartcard and
Section 27.3.10: Single-wire half-duplex communication updated. Bit 12 description
modified in Section 27.6.4: Control register 1 (USART_CR1).
Debug support (DBG) section:
Figure 359: Block diagram of STM32F10xxx-level and Cortex-M3-level debug support
updated
Section 31.15: ETM (Embedded trace macrocell) added
Figure 362: TPIU block diagram updated
–in DBGMCU_IDCODE, REV_ID(15:0) updated for connectivity line devices (revision Z
added).
Section 28: USB on-the-go full-speed (OTG_FS) revised. Small text changes.
Table 232. Document revision history (continued)
