Flexible static memory controller (FSMC) RM0008

518/1096 Doc ID 13902 Rev 12

8 BURSTEN 0x1

7 FWPRLVL Set to protect memory from accidental write access

6 FACCEN Set according to memory support

5-4 MWID As needed

3-2 MTYP 0x1 or 0x2

1 MUXEN As needed

0 MBKEN 0x1

Table 125. FSMC_BTRx bit fields

Bit No. Bit name Value to set

27-24 DATLAT Data latency

23-20 CLKDIV

0x0 to get CLK = HCLK (not supported)

0x1 to get CLK = 2 × HCLK

19-16 BUSTURN no effect

15-8 DATAST no effect

7-4 ADDHLD no effect

3-0 ADDSET no effect
