General-purpose and alternate-function I/Os (GPIOs and AFIOs) RM0008

188/1096 Doc ID 13902 Rev 12

Refer to Table 3 on page 50 for the register boundary addresses.

0x10

AFIO_EXTICR3

Reserved

EXTI11[3:0] EXTI10[3:0] EXTI9[3:0] EXTI8[3:0]

Reset value 0000000000000000

0x14

AFIO_EXTICR4

Reserved

EXTI15[3:0] EXTI14[3:0] EXTI13[3:0] EXTI12[3:0]

Reset value 0000000000000000

0x1C

AFIO_MAPR2

Reserved

FSMC_NADV

TIM14_REMAP

TIM13_REMAP

TIM11_REMAP

TIM10_REMAP

TIM9_REMAP

Reserved

Reset value 000000
