Advanced-control timers (TIM1&TIM8) RM0008

346/1096 Doc ID 13902 Rev 12

Refer to Table 3 on page 50 for the register boundary addresses.

0x40

TIMx_CCR4

Reserved

CCR4[15:0]

Reset value 0000000000000000

0x44

TIMx_BDTR

Reserved

MOE

AOE

BKP

BKE

OSSR

OSSI

LOCK

[1:0]

DT[7:0]

Reset value 0000000000000000

0x48

TIMx_DCR

Reserved

DBL[4:0]

Reserved

DBA[4:0]

Reset value 00000 00000

0x4C

TIMx_DMAR

Reserved

DMAB[15:0]

Reset value 0000000000000000

Table 84. TIM1&TIM8 register map and reset values (continued)
