General-purpose timers (TIM2 to TIM5) RM0008

406/1096 Doc ID 13902 Rev 12

Refer to Table 3 on page 50 for the register boundary addresses.

0x28

TIMx_PSC

Reserved

PSC[15:0]

Reset value 0000000000000000

0x2C

TIMx_ARR

Reserved

ARR[15:0]

Reset value 0000000000000000

0x30

Reserved

0x34

TIMx_CCR1

Reserved

CCR1[15:0]

Reset value 0000000000000000

0x38

TIMx_CCR2

Reserved

CCR2[15:0]

Reset value 0000000000000000

0x3C

TIMx_CCR3

Reserved

CCR3[15:0]

Reset value 0000000000000000

0x40

TIMx_CCR4

Reserved

CCR4[15:0]

Reset value 0000000000000000

0x44

Reserved

0x48

TIMx_DCR

Reserved

DBL[4:0]

Reserve

DBA[4:0]

Reset value 00000 00000

0x4C

TIMx_DMAR

Reserved

DMAB[15:0]

Reset value 0000000000000000

(continued)

Offset Register
