Controller area network (bxCAN) RM0008
668/1096 Doc ID 13902 Rev 12
CAN filter mode register (CAN_FM1R)
Address offset: 0x204
Reset value: 0x00
Note: This register can be written only when the filter initialization mode is set (FINIT=1) in the
CAN_FMR register.
Note: Please refer to Figure 229: Filter bank scale configuration - register organization on
page 642
CAN filter scale register (CAN_FS1R)
Address offset: 0x20C
Reset value: 0x00
Note: This register can be written only when the filter initialization mode is set (FINIT=1) in the
CAN_FMR register.
Note: Please refer to Figure 229: Filter bank scale configuration - register organization on
page 642
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
FBM27 FBM26 FBM25 FBM24 FBM23 FBM22 FBM21 FBM20 FBM19 FBM18 FBM17 FBM16
rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
FBM15 FBM14 FBM13 FBM12 FBM11 FBM10 FBM9 FBM8 FBM7 FBM6 FBM5 FBM4 FBM3 FBM2 FBM1 FBM0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 Reserved. Forced to 0 by hardware.
Bits 27:0 FBMx
: Filter mode
Mode of the registers of Filter x.
0: Two 32-bit registers of filter bank x are in Identifier Mask mode.
1: Two 32-bit registers of filter bank x are in Identifier List mode.
Note: Bits 27:14 are available in connectivity line devices only and are reserved otherwise.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
FSC27 FSC26 FSC25 FSC24 FSC23 FSC22 FSC21 FSC20 FSC19 FSC18 FSC17 FSC16
rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
FSC15 FSC14 FSC13 FSC12 FSC11 FSC10 FSC9 FSC8 FSC7 FSC6 FSC5 FSC4 FSC3 FSC2 FSC1 FSC0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 Reserved, forced by hardware to 0.
Bits 27:0 FSCx
: Filter scale configuration
These bits define the scale configuration of Filters 13-0.
0: Dual 16-bit scale configuration
1: Single 32-bit scale configuration
Note: Bits 27:14 are available in connectivity line devices only and are reserved otherwise.
