Trimble S User Manual

Chapter 3
Theory of Operation
Trimble S, VX, SPS & RTS Service Manual3 - 52 P/N 57150002, Revision 5.0
F
Software / Instrument application firmware
• Software units in Trimble S6
• Software file structure
• Application firmware upgrade
• Software configuration key
• Firmware Compatibility
• Trimble eProtectTM - PIN/PUK code security
• Face2 display start-up menu
• Instrument constant files
Software units in Trimble S6
The following units contains application firmware in the Trimble S6 instrument
Unit Location
IM, Instrument manager IPC board
PCS, Position, Control System IPC board
Distance unit, DR300+ TPD board
Tracker unit OTC board
Servo focus SFC board
Tilt sensor Tilt sensor
PSM, Power Supply Management PSM board
