Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 42 P/N 57150002, Revision 5.0
F
Face 2 Cover
• Face 2 cover replacement
Tools and equipment
Face 2 cover replacement
Performance
Description Part number
Torque wrench 120 Ncm T71600280
Torx T10 bit Local tool
Item Performance Action Results Notes
1 Replace face 2 cover. A. Remove the two
screws.
B. Remove face 2 cover
from instrument.
C. Remove the foam from
the old face 2 cover and
mount it in the new
face 2 cover.
D. Mount face 2 cover and
screws.
35 Ncm. Use a torque wrench
with a torx T10 bit.
Note – Inside the face
2 cover there is a
black foam that will
prevent ambient light
from entering the
instrument and tilt
unit.
Note – When
mounting the face 2
cover make sure the
hooks are in correct
place.
