Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 33 Trimble S, VX, SPS & RTS Service Manual
F
Reticle
• Determination (check) of reticle collimation
• Determination of tracker receiver collimation “ct” and “it”
• Determination of reference angle for reticle adjustment using tracker receiver
• Determination of reference angle for reticle adjustment using centring tool
• Reticle adjustment
• Reticle collimation (HA/VA collimation)
• Trunnion axis correction
• Verification of reticle illumination
Precondition: the angle system is working, see “Angle unit” on page 6-28.
There are three different cases for the reticle / tracker receiver adjustments:
1. Reticle has been replaced or is out of adjustment
2. Tracker receiver (has been replaced or)* is out of adjustment
3. Reticle and tracker receiver has been replaced or is out of adjustment
* replacement is a level 4 service
The flow chart is a guide through the adjustment procedure. In the flow chart, cross references links
to the process for the description of the appropriate adjustment process.
Tools and equipment
Description Part number
Reticle centring tool 79441001
Tracker illumination tool 79445001
Torque wrench 120 Ncm T71600280
2 x Torx T8 bits Local tool
Hexagon screw driver 2mm Local tool
Hexagon screw driver 2,5mm (ball tipped) Local tool
Adjustment pin 1mm Local tool
