Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 82 P/N 57150002, Revision 5.0
F
EDM offset determination
Note – it is a precondition that the baselines have been set in pass/settings/baseline editor. otherwise
they will not appear when assigning baselines in this software.
See page 8-46 for information regarding correct prisms for the EDM offset determination
See PASS user manual how to setup baselines in the baseline editor.
Performance
Fig. 6-91 TCXO frequency calibration
5 Exit software. Click
Exit button.
Item Performance Description Result Notes
1 Start up instrument /
PASS.
See page 7-3 how to set-
up the instrument.
2 Start the offset
determination.
Select
Offset
determination
from EDM
in
Final Test & report, see
Fig. 6-92 on page 6-83 .
Item Performance Action Results Notes
