Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 119 Trimble S, VX, SPS & RTS Service Manual
F
TCXO Frequency Calibration
Availability of a Frequency counter with the following specification is necessary.
Range: 100Hz-300MHz
Uncertainty: <1x 10 -7 at (23 ± 3) °C / per year
Resolution: 10 digits, max. 0,1mHz
e.g. Fluke PM6685/-5- with OCXO
This TCXO calibration correction value is used for exact calculation of distances. The transmitted
frequency and the TCXO frequency on the Transceiver board will be changed.
Performance
8 Distance measurement
in Reflector mode.
A. Aim to a prism target,
no specific distance
required.
B. Click
Prism measure
button.
C. Click
Stop to finnish
test.
High Precision /
DR Standard
<1mm
DR <2mm
Item Performance Action Results Notes
1 Start up instrument /
PASS.
2 Start service software. A. Select
TCXO Frequency
calibration
from EDM
High Precision
in
Maintenance & service.
3. Measure and correct
TCXO frequency.
A. Select
TCXO calibration
check box.
B. Measure the frequency
on the Transceiver
board and type in the
value.
C. The TCXO correction
is displayed.
D. Click
Save button to
store the correction
value in the
instrument.
E. Repeat the measure
sequence B, C & D
until the measured
frequency is in
tolerance.
Possible
frequency
range:
14985798 -
14985802 Hz
High precision
Frequency counter is
required, 0,1 Hz
resolution.
After saving the
correction value, the
TCXO frequency
will be corrected and
a new frequency
value can be
measured.
Item Performance Description Result Notes
