Trimble S - Regreasing of centre unit axes; Regreasing Servo Axle and Bearing

Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 50 P/N 57150002, Revision 5.0
F
Regreasing of centre unit axes
• Regreasing Servo Axle and Bearing
• Regreasing Battery/Radio Axle and Bearing
Tools and Equipment
Regreasing Servo Axle and Bearing
Performance
Description Part number
Torque wrench, 500 T71600281
Torx 10 bit Local tool
Puller Vertical Axle 59280001
Isoflex 3000 (grease) R71905945
Item Performance Action Result Notes
1 Remove servo side
cover.
Lay the instrument on
the side with the servo
side cover up and
remove servo side cover.
2 Remove the IPC board.
3 Remove Telescope pre-
load unit.
4 Remove SRC board. Remove SRC board incl.
magnets together with
the vertical angle disc.
5 Remove MSB board. Remove MSB board
incl. motor winding.
6 Remove the four screw
holding the axle
Note – Do not loosen
or remove the four
screws that hold the
bearing as this will
affect the accuracy
of the instrument
(marked with red
cross in see Fig. 5-
48 on page 5-51 .
7 Remove the axle Mount the Puller
Vertical Axle tool and
pull out the axle by
rotating the knob
clockwise see Fig. 5-48
on page 5-51
Note – Do not move
the instrument when
the axle is removed.
