Replacements of Greywedge assembly
Performance
Replacement of Reference greywedge
Performance
Item Performance Action Results Notes
1 Greywedge assembly. To remove the greywedge
assembly follow
instructions Distance unit
parts replacement on page
5-72.
To mount the greywedge
assembly proceed after
item 10, see Fig. 5-70 on
page 5-74 .
Item Performance Action Results Notes
1 Remove Handle and
Cover
Remove the handle of the
instrument.
Remove the distance unit
cover, see page 5-3.
2 Remove board holder Pull up the holder, go to
item 2, see page 5-72.
3 Remove Receiver
board
Disconnect the ribbon
cable A, see Fig. 5-68 on
page 5-73 .
Place the Receiver board
in vertical position.
Lay down the instrument
on the servo side cover.
This avoids the drop
down of the screw
and leaf spring into
the center unit.
4 Remove reference
greywedge
A. Loose the screw and
remove the leaf spring.
B. Exchange the
Reference greywedge.
C. Position the black-
white crossing of the
Reference greywedge
as shown in Fig. 5-79
on page 5-82 and push
the axis downwards to
the bottom.
Screw driver Torx
T6, bended (15mm)
or with longer shaft is
recommended.
This makes easier to
find the correct
reference pulse.
To Next Page
