Trimble S - Tilt sensor; Tilt sensor replacement

Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0 5 - 67 Trimble S, VX, SPS & RTS Service Manual
F
Tilt sensor
• Tilt sensor replacement
Tools and equipment
Tilt sensor replacement
Performance
Description Part number
Torque wrench 120 Ncm T71600280
Torx T8 bit Local tool
Item Performance Action Results Notes
1 Remove servo side
cover.
See page 5-15.
2 Remove IPC board. See page 5-17.
3 Remove battery/radio
side cover.
See page 5-10.
4 Remove horizontal
turning unit.
See page 5-55.
5 Remove TCU
attachment.
See page 5-20.
6 Remove optical
plummet.
See page 5-38.
7 Remove face 2 panel. See page 5-39.
8 Disconnect cable to
pressure sensor.
See page 5-40.
9 Remove PSM board. See page 5-65.
10 Replace tilt sensor. A. Remove the three
screws
B. Replace tilt sensor.
C. Mount tilt sensor
towards the two end
stops.
55 Ncm. Use a torque wrench
with a torx T10 bit.
