Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 51 Trimble S, VX, SPS & RTS Service Manual
F
Laser pointer - DR300+ / DR PLUS
• Laser pointer alignment
Trimble S6 High Precision / DR Standard / DR laser pointer is the same light source as the EDM
transmitter. See page 6-90 for alignment instructions.
Laser pointer and tracker transmitter are aligned together. When aligning the laser pointer the tracker
transmitter will also be aligned.
The tracker transmitter can be aligned separately, see page 6-139.
Tools and equipment
Laser pointer alignment
Performance
Description Part number
Grey filter 7027229001973
Adapter ring 79554001
Cable pointer illumination 79772001
Target S6 Tx adjustment 59002026
Item Performance Description Result Notes
1 Start up instrument /
PASS.
See page 7-3 how to set-up
the instrument.
2 Prepare instrument. A. Place the instrument on
Collimator.
B. Set the collimator wave
length to 2.
C. If the distance unit
boards are removed,
then supply the Laser
pointer with 5 volt by
the cable pointer
illumination.See Fig.
6-43 on page 6-52
C
Caution – The EDM
transmits a laser
beam.
