High Power Laser Pointer - HPL
Trimble S8 with High Power Laser Pointer requires PASS 1.6 or higher.
C
Warning – use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous led or laser radiation exposure. as with any bright light
source, such as the sun, electric welding arcs or arc lamps, common sense applies. Avoid direct
eye exposure when the laser is on. for further information regarding safe use of lasers, refer to
the CEI/IEC standard 60825-1:2007.
Laser safety
The High Power Laser Pointer option is a Class 3R Laser Pointer. See page 1-8 for information about
laser safety and laser classes.
C
Warning – Avoid aiming the Class 3R Laser Pointer towards any person.
Service recommendation – Position the collimator equipment to avoid accidental aiming to any
person
Fig. 6-194 Laser warning labels
High Power
Laser pointer
warning label
Laser 3R
warning label
High Power Laser
pointer apperture
High Power Laser
pointer apperture
Laser apperture
label
