Trimble S - Tracker unit; Tracker receiver alignment - (replacement Level 4 only)

Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 110 P/N 57150002, Revision 5.0
F
Tracker unit
• Tracker receiver alignment - (replacement Level 4 only)
• OTA board replacement
• OTC board replacement
• Tracker transmitter
Tools and equipment
Tracker receiver alignment - (replacement Level 4 only)
Tracker receiver replacement is a level 4 service but realignment is possible within the screw holes.
Performance
Description Part number
Torque wrench 120 Ncm T71600280
Torx 8 bit Local tool
Screw driver 2 mm Local tool
Straight point Tweezers Local tool
Item Performance Action Result Notes
1 Remove tracker unit
cover.
See page 5-3. For laser safety
information,See page
1-8.
2 Remove TFB, OTC,
OTA board and
Tracklight group.
See page 5-113, Item 2; 3
and 4.
3 Remove tracker
receiver.
A. Remove the four
screws.
B. Lift up and remove the
receiver.
Note – Do not place the
tracker receiver wit the
lens down Dust, dirt or
fingerprints will affect the
tracker performance. If so
clean using alcohol &
water
The bars are glued to
the receiver housing.
