OTA board replacement
For OTA replacement instructions see “Tracklight replacement” on page 5-113..
OTC board replacement
For OTC replacement instructions see “Tracklight replacement” on page 5-113..
Tracker transmitter
Tracker transmitter is mounted together and aligned with the Laser pointer, see “Laser pointer -
DR300+ / DR PLUS” on page 5-87. for replacement instructions.
