Trimble S - Display and;or display gasket replacement

Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0 5 - 31 Trimble S, VX, SPS & RTS Service Manual
F
Display and/or display gasket replacement
Performance
7 Mount quimby board Mount Quimby board
to the display frame
and tighten the screws
with a torque wrench
40 Ncm.
8 Connect cables Connect cables A-C to
the Quimby board, See
page 5-30
Cable:
A. Quimby board to
KBDQ board
B. Quimby board to
Display
C. Quimby board to
Loudspeaker
9 Mount IAB frame Mount IAB frame and
tighten the 4 screws
with a torque wrench
40 Ncm.
10 Mount IAB board See page 5-27
11 Mount back cover See page 5-25
12 Mount control panel
on instrument
See page 5-24
Item Performance Action Result Notes
1 Remove control panel
from instrument
See page 5-24
2 Remove back cover See page 5-25
3 Disconnect cables Disconnect cable A-C Cable:
A. Quimby board to
KBDQ board
B. Quimby board to
Display
C. Quimby board to
Loudspeaker. Draw
the cable
underneath the IAB
frame according to
the white arrows,
see Fig. 5-31 on
page 5-32
Item Performance Action Result Notes
