Trimble S User Manual

Chapter 8
Replacement Parts & Tooling
P/N 57150002, Revision 5.0 8 - 47 Trimble S, VX, SPS & RTS Service Manual
F
Baselines
Trimble DR High Precision / DR Standard instruments
Trimble DR 300+ instruments
Target Description Distance
1 Prism for EDM offset determination Between 10-100 m
2 Prism for EDM offset determination Between 10-100 m
3 Prism for EDM offset determination Between 10-100 m
4 Prism for EDM offset determination Between 10-100 m
5 Prism for validation Between 10-100 m
6 DR Target for validation Between 2.4-2.6 m
7 DR Target for validation Between 15-50 m
Note – Do not use the same targets for determination and
validation, the distances have to be different. The
recommended quantity of target for determination is a
minimum and can be increased depend on the local set-up.
Target Description Distance
1 Prism for EDM offset determination Between 10-100 m
2 Prism for EDM offset determination Between 10-100 m
3 Prism for EDM offset determination Between 10-100 m
4 DR Target for DR offset determination Between 15-50 m
5 DR Target for DR offset determination Between 15-50 m
6 DR Target for short range determination Between 2.4-2.6 m
7 Prism for validation Between 10-100 m
8 DR Target for validation Between 2.4-2.6 m
9 DR Target for validation Between 15-50 m
Note – Do not use the same targets for determination and
validation, the distances have to be different. The
recommended quantity of target for determination is a
minimum and can be increased depend on the local set-up.
